±0.005mm Hot Runner Injection Mold
Product Details:
| Place of Origin: | Dongguan China |
| Brand Name: | GT |
| Certification: | ISO 9001 , IGS |
| Model Number: | Hot Runner Injection Mold |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 mold |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Woodencase for packaging mold & Carton Box for packaging products |
| Delivery Time: | 20 days after 2D 3D confirmed |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 65 molds / month |
|
Detail Information |
|||
| Mold Type: | Hot Runner Injection Mold | Mould Life: | 500000-600000 Shots |
|---|---|---|---|
| Design Software: | UG , PROE , CAD | Plastic Material: | PP, PC , PS , PE |
| Mould Material: | H13 , 2738 , S136 , SKD61 | Mould Base: | Futaba , Lkm , Hasco , Dme |
| Cavity: | Single Mould | Tolerance: | Up To 0.01mm |
| Highlight: | ±0.005mm Hot Runner Injection Mold,SKD61 Hot Runner Injection Mold,±0.005mm hot runner plastic injection |
||
Product Description
Specifications:
1. Quote competitive price according customer detail requirement
2. Sign agreement.
3.Customer T/T deposit to us to design mould
4.Send mould drawing to customer for confirmation
5. Mould design confirmed and start to make mould.
6. Make mould trial during tooling time(which we get agreement with customer).
7. Seed mould trial sample to customer for inspection.Or customer come to our factory to inspect mould
personally.
8. Customer T/T balance to us after mould confirmed.
9. Deliver mould after get balance.
|
Company Name |
TAKDA PRECISE MOULD FACTORY |
|
Business type |
Manufacturer |
|
Main Product |
CNC Milling, Plastic Mould/Tooling, Prototype, Molding Product, Injection Foaming Mold, 3D Printing,Die Casting,Gas Assisted Injection Molding |
|
Mould Base |
SD,LKM Standard, HASCO Standard Self-made, etc. |
|
Mould Material |
P20/718/738/NAK80/S136/2738/2316/H13, etc. |
|
Moud Precision |
+/-0.01mm |
|
Mould Life |
50-500K shots |
|
Mould Cavity |
Single cavity, multi-cavity |
|
Runner System |
Hot runner and cold runner |
|
GateType |
Pinpoint Gate, Edge Gate, Sub Gate, Film Gate, Valve Gate, Open Gate, etc. |
|
Equipment |
CNC,EDM,Cutting off Machine,plastic machinery,etc plastic part |
|
Plastic Material |
PA6,PA66, ASA, POM, PPS,ABS,ABS+GF,ABS+PC,POM(Derlin),PP, PE,PC,PMMA(Acrylic),PVC,PEI,PBT,PTFI |
|
Metal Material |
Aluminum (6061,6063,7075...),Brass, Copper, Brass,Satinless Steel(301,302,303,304...) |
|
Surface Treatment |
Polishing,Painting,Chroming,Anodizing, Brushing, Silk Screening,Water Transfering, Laser Cutting,Leather Covering,Texture, Sanblasting,Gilding, UV Painting… |
|
Pls Provide |
2D, 3D, samples, or the size of the multi-angle pictures |
|
Quanlity System |
ISO 9001: 2019 |
|
We Promise |
All customer-centric, never for short-term profit, and sell long-term benefits |
Applications:
The mould is made with many complicated slides and inserts.We can customize diverse moulds for our clients based on the 3D drawing they provide, such as the electronic part mould, plastic injection mould, die-casting mould and so on.
Description:
| Mould material | 45#, 50#, P20, H13, 718, 2738, NAK80, S136, SKD61 etc. |
| Mould base | LKM, HASCO etc. |
| Cavity | Single/multi |
| Runner | Hot/cold |
| Design software | UG, PROE, CAD, CAXA etc. |
| Plastic material | PP, PC, PS, PE, PU, PVC, ABS, PMMA etc. |
| Mould life | 300,000-3,000,000 shots |
| Delivery time | 15-60days |
| Specification | Depends on customer's requirements |
| Mold doff way | Doff plate, ejectors, air valves, hydraulic jar, etc |
| Mold hot treatment | Including quencher, tempering, etc |
| Mold cooling system | Water cooling or Beryllium bronze colling, etc |
