High Precision RoSH LKM Base Plastic Injection Parts
Product Details:
Place of Origin: | Dongguan China |
Brand Name: | GT |
Certification: | ISO 9001 , IGS |
Model Number: | Stirring Teeth Mold |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 mold |
---|---|
Price: | Negotiate |
Packaging Details: | Woodencase for packaging mold & Carton Box for packaging products |
Delivery Time: | 20 days after 2D 3D confirmed |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 65 molds / month |
Detail Information |
|||
Mold Type: | Stirring Teeth Mold | Runner: | Cold / Hot |
---|---|---|---|
Design Software: | UG , PROE , CAD | Plastic Material: | PP, PC , PS , PE |
Mould Material: | H13, NAK80, S136, SKD61 | Mould Base: | Futaba , Lkm , Hasco , Dme |
Cavity: | Single Mould | Tolerance: | Up To 0.01mm |
High Light: | LKM Base Plastic Injection Parts,RoSH Plastic Injection Parts,RoSH custom plastic molding |
Product Description
◆ 35 High speed electro-motion injection machines imported from Japan, ranging from 30T to 140T from Nissei, JSW, Sumitomo....
◆ 25 Hydraulic Plastic Injection machines imported from Nissei Japan, ranging from 50T to 380T
◆ 2 sets of Double injection machines worked in Dust-free workshop, which usded especially for producing optical Lens and transparent parts, double injection parts.
◆ 6 Advanced CNC machines: Charmilles, Seiki, MITSUBISHI
◆ 4 Advanced EDM : CHARMILLES, SODICK
◆ 2 Advanced WEDM: CHARMILLES, SODICK
◆ 120 workers are dedicated to providing perfect products for customers.
◆ 20 mold designer can quickly respond to customers needs ( It contains 3 engineers with 10+ years' experience can work together with customers for completing and optimizing the products to be more manufacturable)
M/C | Qty.(set) | Precision |
CNC machining center | 6 | 0.02mm |
Hi-speed CNC machining Center | 2 | 0.01mm |
CNC engraving machine | 2 | 0.01mm |
Injection molding machine | 4 | -- |
Electric discharge spark machine | 2 | 0.005mm |
High precision servo thread cutting | 2 | 0.01mm |
Precision piercing machine | 1 | 0.3mm |
Hingh Speed Machining Center | 1 | 0.01mm |
Grinding machine | 3 | 0.002mm |
Precision large water grinder | 1 | 0.005mm |
Milling machine | 3 | 0.005mm |
Radial drill | 1 | 0.1mm |
Specifications:
1. Quote competitive price according customer detail requirement
2. Sign agreement.
3. Customer T/T deposit to us to design mould
4. Send mould drawing to customer for confirmation
5. Mould design confirmed and start to make mould.
6. Make mould trial during tooling time(which we get agreement with customer).
7. Seed mould trial sample to customer for inspection.Or customer come to our factory to inspect mould
personally.
8. Customer T/T balance to us after mould confirmed.
9. Deliver mould after get balance.
Product Description
|
Router Injection Mold | ||
Plastic Materials:
|
PS, ABS, PP, PVC, PMMA, PBT, PC, POM, PA66, PA6, PBT+GF, PC/ABS, PEEK, HDPE, TPU, PET, PPO,...etc.
|
||
Other materials:
|
Rubber, Slilconce rubber, LSR,Aluminum, Zinc,Copper...Metal...etc.
|
||
Quality:
|
RoSH and SGS standard
|
||
Feature:
|
Non marking and Non flash
|
||
Size:
|
According to your 2D or 3D Drawing
|
||
Color,Quantity,Unit price,Tooling cost,Tooling size:
|
To be discussed
|
||
Package:
|
Standard exported Wooden box packed, Fumigation process(upon required)
|
||
Mold Building Lead Time:
|
T1, 4-5 weeks, Part measurement report (upon required).
|
||
Export Country:
|
Europe, America, Australian, UK, Canada, France, Germany, Italy, Japan...etc.:
|
||
To be discussed
|
In-Mold Decoration, Injection Mould, Plastic Mold, Overmould, 2K Mould, Die-Casting Mould, Thermoset Mold, Stack Mold,
Interchangeable Mold,Collapsible Core Mold, Die Sets, Compression Mold, Cold Runner System LSR Mold,...etc. |
||
Mould Base:
|
Hasco Standard, European Standard, World Standard
|
||
Mould Base Material:
|
LKM, FUTA, HASCO, DME,...etc. Or as per Customer's Requirment.
|
||
Surface Finish:
|
Texture(MT standard), High gloss polishing
|
||
Cavity/Core Steel:
|
P20, 2311, H13, 2344, Starvax 420, 236, AdC3, S136, 2312, 2379, 2316, 2083, Nak80, 2767 ...etc.
|
||
Hot/ Cold Runner
|
HUSKY, INCOE, YDDO, HASCO, DME, MoldMaster, Masterflow, Mastip, Taiwan made brand...etc.
|
||
Mould Life:
|
5,000 to 1,000,000 Shots. (According to your working environment.)
|
||
Design & Program Softwares:
|
CAD, CAM, CAE, Pro-E, UG, Soild works, Moldflow, CATIA....etc.
|
||
Equipments:
|
High speed CNC, Standard CNC, EDM, Wire Cutting, WEDM, Grinder, Plastic Injection Molding Machine for trial out mold from 50-3000T
available. |
Mould Processing Detail Time Schedule
|
||||||
Prepare Mold Steel
|
CNC Machining
|
Precision CNC Machining
|
Drill
|
Polishing/Carving
|
Assembling and Fitting
|
T1 Mould Test
|
5 days
|
10 days
|
5 days
|
5 days
|
3-5 days
|
5 days
|
2 days
|
Competitive Advantage:
1. We keep long term cooperation with some world Top Brand on electronic product area, such Epson,
Canon and Sony.
2. We have successfully gained the quality certificate of ISO 9001 and IGS.
3. We can design and manufacture the mould in different specification and standard, such as DME,HASCO
and DAIDO.
4. The factory is well equiped with the most advanced testing instrument, it is effective to ensure the precision
of the mould.
5. Strict quality control;
6. Good After-sale service;
7. On time delivery
